MikroTik CRS326-24G-2S+IN

Name: MikroTik CRS326-24G-2S+IN
Brand: MikroTik
SKU: CRS326-24G-2S+IN
Price: 193.97 EUR
Availability: InStock

Product.Nr.: CRS326-24G-2S+IN

Manufacturer: MikroTik

193,97 EUR
incl. 19 % VAT

excl. shipping costs

Sofort versandfähig
delivery time sofort lieferbar
weight 1,6 kg

product description

#1: CRS326-24G-2S+IN

A home network setup doesn’t have to be a compromise. This compact and quiet switch is packing some serious server room grade features: a pair of 10G SFP+ cages, 512 MB of RAM, 24 Gigabit Ethernet ports and a sufficient built-in CPU that can handle basic home user needs such as firewall, NAT and even some VPN. And it is extremely affordable – we are keeping the price on par with the previous generation desktop switches!

Like many other MikroTik switches, CRS326-24G-2S+IN offers the dual boot option that allows you to use either the lightweight SwOS or the advanced RouterOS. The compact and quiet fanless desktop case makes this switch the perfect addition to the best home setups. And it is very easy to transport! But make no mistake – this small switch has all the power and features of its bigger rackmount analogue – the CRS326-24G-2S+RM, nothing has been removed!

CRS326-24G-2S+IN provides all the basic functionality for a managed switch, and even more: port-to- port forwarding, MAC filtering, VLAN configuration, traffic mirroring, bandwidth limitation and even adjust some MAC and IP header fields. SFP+ cage supports both 1.25G SFP and 10G SFP+ modules.

#2: Included in delivery

1x CRS326-24G-2S+IN
1x 24V 1,2A power supply

#3: Specifications - Technical details

Details
Product code	CRS326-24G-2S+IN
Architecture	ARM 32bit
CPU	98DX3236
CPU core count	1
CPU nominal frequency	800 MHz
Switch chip model	98DX3236
Dimensions	285 x 144 x 44 mm
RouterOS license	5
Operating System	RouterOS / SwitchOS
Size of RAM	512 MB
Storage size	16 MB
Storage type	FLASH
MTBF	Approximately 200'000 hours at 25C
Tested ambient temperature	-40°C to 60°C

Powering

Details
Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input Voltage	10-30 V
Max power consumption	21 W
Cooling type	Passive
PoE in	Passive PoE
PoE in input Voltage	10-30 V

Ethernet

Details
10/100/1000 Ethernet ports	24

Fiber

Details
SFP+ ports	2

Peripherals

Details
Serial console port	RJ45

Certification & Approvals

Details
Certification	CE, EAC, ROHS
IP	IP20

#4: Test results according to RFC2544

Switching results

CRS326-24G-2S+INr2
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Switching	Non blocking Layer 2 throughput	3,576.1	43,427.8	10,338.3	42,345.9	65,476.2	33,523.8
Switching	Non blocking Layer 2 capacity	3,576.1	86,855.7	10,338.3	84,691.7	65,476.2	67,047.6
Switching	Non blocking Layer 1 throughput	3,576.1	44,000.0	10,338.3	44,000.0	65,476.2	44,000.0
Switching	Non blocking Layer 1 capacity	3,576.1	88,000.0	10,338.3	88,000.0	65,476.2	88,000.0

Ethernet test results

CRS326-24G-2S+INr2		98DX3236 all port test
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	104,3	1266.6	273,5	1120.3	449	229.9
Bridging	25 bridge filter rules	104	1263.0	104,6	428.4	104,5	53.5
Routing	none (fast path)	104,3	1266.6	273,9	1121.9	343,5	175.9
Routing	25 simple queues	104,3	1266.6	136,9	560.7	137,4	70.3
Routing	25 ip filter rules	64,8	786.9	65,9	269.9	65,8	33.7

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
