Mikrotik SXTsq Lite2
36,89 EUR
incl. 19 % USt
(Netto: 31,00 EUR)
Gewicht: 0,50 KG
Sofort versandfähig
Art.Nr.: RBSXTsq2nD
Produktbeschreibung
Mikrotik RBSXTsq2nD - SXTsq Lite2
Mikrotiks SXTsq Lite2 ist eine kompakte und leichte Funkantenne für den Aussenbereich (die Antenne ist direkt integriert). Sie eignet sich perfekt für Punkt-zu-Punkt-Links oder als CPE Einheit. Sie ist kompakt, wetterfest und einfach zu montieren.
Sie verfügt über eine 10 dBi Antenne, wie man es schon von dem vorherigen Model, der SXT Lite2, kennt. Das Antennendesign wurde jedoch verbessert und die physikalische Größe deutlich reduziert - Die SXTsq ist zweimal dünner.
-
Specifications
| Details | |
|---|---|
| Product code | RBSXTsq2nD |
| Architecture | MIPSBE |
| CPU | QCA9533 |
| CPU core count | 1 |
| CPU nominal frequency | 650 MHz |
| Dimensions | 129 x 129 x 34 mm |
| License level | 3 |
| Operating System | RouterOS |
| Size of RAM | 64 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| Tested ambient temperature | -40°C .. +70°C |
Powering
| Details | |
|---|---|
| Max Power consumption | 5W |
| PoE in | Passive PoE |
| PoE in input Voltage | 10-30 V |
| Number of DC inputs | 1 (PoE-IN) |
Wireless
| Details | |
|---|---|
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 10 |
| Wireless 2.4 GHz chip model | QCA9533 |
Ethernet
| Details | |
|---|---|
| 10/100 Ethernet ports | 1 |
Wireless specifications
| 2.4 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 1MBit/s | 30 | -100 |
| 11MBit/s | 30 | -93 |
| 6MBit/s | 30 | -94 |
| 54MBit/s | 26 | -80 |
| MCS0 | 30 | -94 |
| MCS7 | 25 | -75 |
-
Ethernet test results
| RBSXTsq2nD | QCA9533 100M one port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 8.1 | 98.4 | 23.5 | 96.3 | 173.6 | 88.9 |
| Bridging | 25 bridge filter rules | 8.1 | 98.4 | 23.5 | 96.3 | 70.9 | 36.3 |
| Routing | none (fast path) | 8.1 | 98.4 | 23.5 | 96.3 | 160.8 | 82.3 |
| Routing | 25 simple queues | 8.1 | 98.4 | 23.5 | 96.3 | 90.8 | 46.5 |
| Routing | 25 ip filter rules | 8.1 | 98.4 | 23.5 | 96.3 | 43.2 | 22.1 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
Downloads
| Datei | Dateigröße | ||
 |
sxtsq-lite2-QuickGuide.pdf | 0.14 MB |  |
|
sxtsq-lite2-Brochure.pdf | 1.72 MB | |
|
sxtsq-lite2-SelectionGuide-PTP.pdf | 4.78 MB | |
|
sxtsq-lite2-SelectionGuide-PtMP.pdf | 3.84 MB | |
|
sxtsq-lite2-BlockDiagramm.pdf | 0.03 MB | |
