#1: nRAYG-60adpair - Wireless Wire nRAY

MikroTiks team has gathered and taken into account your feedback to make a worthy successor of our popular Wireless Wire Dish. Now they are proud to present the best plug-and-play 60 GHz point-to-point link solution to date - the Wireless Wire nRAY. It is a kit of two pre-paired devices that make a secure AES encrypted wireless connection.

It can easily cover a distance of 1500 meters and reach fiber-like speed, and we have made some serious structural improvements. With the latest antenna technologies, this device is very compact, but even more durable than its predecessors.

 The new form-factor has been designed with snowy areas in mind – you won’t have to worry about huge chunks of snow getting stuck and messing with the signal. Due to its size and shape, the nRAY also attracts less unwanted attention. Using the special fine-tune adjustment screws, a perfect alignment can be achieved.

The 60 GHz frequency is unaffected by the crowded wireless spectrum, so you can enjoy a smooth connection even in a busy urban environment. A powerful arm64 dual-core CPU running at 1 GHz ensures wire speed throughput in nearly all packet sizes. The included devices are preconfigured to connect automatically, simply point them at one another and power them on! We have included the power supplies, PoE injectors and a handy precision mount for easier alignment - the solidMOUNT. It is an advanced pole mount metal adapter that allows adjustment both vertically and horizontally.

#2: Im Lieferumfang enthalten | Included in delivery

#3: Spezifikationen - Technische Details | Specifications - Technical details

• Product code nRAYG-60adpair

• Architecture ARM 64bit

• CPU 88F3720

• CPU core count 2

• CPU nominal frequency 1 GHz

• CPU Threads count 2

• Dimensions 261 x 166 mm

• RouterOS license 3

• Operating System RouterOS

• Size of RAM 256 MB

• Storage size 16 MB

• Storage type FLASH

• MTBF Approximately 200'000 hours at 25C

• Tested ambient temperature -30°C to 70°C

Powering

• Number of DC inputs 1 (PoE-IN)

• Max power consumption 7 W

• PoE in 802.3af/at

• Cooling type Passive

• PoE in input Voltage 12-57 V

Ethernet

• 10/100/1000 Ethernet ports 1

Certification & Approvals

• Certification CE, FCC, IC, EAC, ROHS

• IP 55

Hinweis/Note:

• Auf dem Gerät ist ein Betriebssystem vorinstalliert und lizenziert. Es ist kein separater Kauf erforderlich, und das Produkt ist sofort einsatzbereit. Das Gerät umfasst kostenlose Software-Updates für die gesamte Lebensdauer des Produkts oder für mindestens 5 Jahre ab Kaufdatum.
• The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.

#4: Test Resultate nach RFC2544 | Test results according to RFC2544

• All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
• Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
• Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

#5: Produktinformationen & Hilfe | Product informations & Help

Produktspezifische Links - Product-specific links:

Sonstige, hilfreiche Links - Other useful links:
