MikroTik RB911-5Hn - 911 Lite5
Art.Nr.: RB911-5Hn
Hersteller: MikroTik
11,90 EUR
UVP 34,90 EUR
Sie sparen 65.9% (23,00 EUR)
incl. 19 % USt
-
- Gewicht 0,2 kg
#1: RB911-5Hn - 911 Lite5
Perfekt für den Aufbau kostengünstiger CPE-Geräte. Der RB911-5Hn ist ein kleiner CPE RouterBOARD Wireless Router mit einer integrierten 5Ghz Single Chain Wireless Karte. Er ist mit einer leistungsstarken 600Mhz CPU ausgestattet und bietet ein hervorragendes Preis-Leistungs-Verhältnis.
- Der RB911-5Hn (International) unterstützt den Frequenzbereich von 5150MHz-5875MHz (Der spezifische Frequenzbereich kann durch länderspezifische Vorschriften eingeschränkt sein).
#2: Im Lieferumfang enthalten
- 1x RB911-5Hn (911 Lite5)
#3: Spezifikationen - Technische Details
| Details | |
|---|---|
| Product code | RB911-5Hn |
| Architecture | MIPSBE |
| CPU | AR9344 |
| CPU core count | 1 |
| CPU nominal frequency | 600 MHz |
| Dimensions | 105x105mm |
| RouterOS license | 3 |
| Operating System | RouterOS |
| Size of RAM | 64 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 100'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
Powering
| Details | |
|---|---|
| Number of DC inputs | 1 (PoE-IN) |
| Max power consumption | 5 W |
| Cooling type | Passive |
| PoE in | Passive PoE |
| PoE in input Voltage | 8-30 V |
Wireless specifications
| Details | |
|---|---|
| Wireless 5 GHz Max data rate | 150 Mbit/s |
| Wireless 5 GHz number of chains | 1 |
| Wireless 5 GHz standards | 802.11a/n |
| Wireless 5 GHz chip model | AR9344 |
| Wireless 5 GHz generation | Wi-Fi 4 |
Ethernet
| Details | |
|---|---|
| 10/100 Ethernet ports | 1 |
Certification & Approvals
| Details | |
|---|---|
| Certification | CE, FCC, IC, EAC, ROHS |
Wireless specifications
| 5 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 6MBit/s | 23 | -93 |
| 54MBit/s | 19 | -74 |
| MCS0 | 23 | -93 |
| MCS7 | 18 | -68 |
#4: Test-Resultate nach RFC2544
Ethernet test results
| RB911-5Hn | AR9344 100M 1 port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 8.1 | 98.4 | 23.5 | 96.3 | 148.0 | 75.8 |
| Bridging | 25 bridge filter rules | 8.1 | 98.4 | 23.5 | 96.3 | 87.6 | 44.9 |
| Routing | none (fast path) | 8.1 | 98.4 | 23.5 | 96.3 | 148.0 | 75.8 |
| Routing | 25 simple queues | 8.1 | 98.4 | 23.5 | 96.3 | 106.6 | 54.6 |
| Routing | 25 ip filter rules | 8.1 | 98.4 | 23.5 | 96.3 | 60.5 | 31.0 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
#5: Produktvideo & Tipps
- Produktvideo: -
- Hinweise für den Start und Umgang mit RouterOS in unserem Blog: RouterOS, Reset, Netinstall, Winbox, Wiki, Supout.rif, 60GHz Ausrichtung uvm
RB911-5Hn-Brochure.pdf (1.14 MB)
RB911-5Hn-Design-files-Step.zip (0.62 MB)
