MikroTik CRS812-8DS-2DQ-2DDQ-RM - CRS812 DDQ
Product.Nr.: CRS812-8DS-2DQ-2DDQ-RM
Manufacturer: MikroTik
https://mikrotik.com/product/crs812_ddq
1.170,50 EUR
incl. 19 % VAT
-
Zur Zeit nicht lagernd, bitte per E-Mail anfragen.
- delivery time auf Anfrage: sales@mikrotik-store.eu
- weight 5,4 kg
product description
#1: CRS812-8DS-2DQ-2DDQ-RM - CRS812 DDQ
400G used to mean expensive, complex, and out of reach. The CRS812 DDQ changes that! With a modern Marvell switch chip and powerful ARM CPU, it delivers advanced routing, switching, and traffic management features trusted in millions of RouterOS deployments – now with ports up to 400 Gbps!
Where does it fit?
- Top-of-rack / leaf switch with 400G uplinks to the spine
- Campus core bridging 10G legacy with modern 50G interfaces
- Service provider aggregation node
- Labs, AI clusters, media workflows where fast “east–west” traffic is critical
The CRS812 scales your network from 10 to 400G in one simple, affordable, yet managed RouterOS v7 box – no forklift upgrades needed!
With CRS812, 400 Gigabits is no longer out of reach – it’s an affordable way to launch your network into the future, while keeping your existing gear in the loop!
#2: Im Lieferumfang enthalten | Included in delivery
| 1x | CRS812-8DS-2DQ-2DDQ-RM | |
| 2x | Kaltgerätekabel | (IEC cords) |
| 1x | Rackmontage-Halterungen hinten (2/2) | (Rackmount rear support ears (2/2)) |
| 1x | Rackmount Halterungen (CRS) | (Rackmount ears (CRS)) |
| 1x | Befestigungsset K-82 | (K-82 fastening set) |
- All available MikroTik [SFP/QSFP] modules can be found here in our shop: [SFP/QSP]
#3: Spezifikationen - Technische Details | Specifications - Technical details
| Details | |
|---|---|
| Product code | CRS812-8DS-2DQ-2DDQ-RM |
| Architecture | ARM 64bit |
| CPU | AL52400 |
| CPU core count | 4 |
| CPU nominal frequency | 2000 MHz |
| Switch chip model | 98DX7335 |
| RouterOS license | 6 |
| Operating System | RouterOS v7 |
| Size of RAM | 4 GB |
| Storage size | 512 MB |
| Storage type | NAND |
| Tested ambient temperature | -10°C to 50°C |
Powering
| Details | |
|---|---|
| Number of AC inputs | 2 |
| AC input range | 100-240 |
| Number of PSU slots | 2 |
| Frequency (Hz) | 50-60 |
| Max power consumption | 134 W |
| Max power consumption without attachments | 81 W |
| Cooling type | 4 fans |
Ethernet
| Details | |
|---|---|
| Number of 1G/2.5G/5G/10G Ethernet ports | 2 |
Peripherals
| Details | |
|---|---|
| Serial console port | RJ45 |
Other
| Details | |
|---|---|
| CPU temperature monitor | Yes |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
Certification & Approvals
| Details | |
|---|---|
| Certification | CE, EAC, ROHS |
| IP | 20 |
#4: Test Resultate nach RFC2544 | Test results according to RFC2544
Switching results
| CRS812-8DS-2DQ-2DDQ-RM | |||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Switching | Non blocking Layer 2 throughput | 131752.3 | 1600000.0 | 390625.0 | 1600000.0 | 810000.0 | 414720.0 |
| Switching | Non blocking Layer 2 capacity | 131752.3 | 3200000.0 | 390625.0 | 3200000.0 | 810000.0 | 829440.0 |
| Switching | Non blocking Layer 1 throughput | 131752.3 | 1621080.2 | 390625.0 | 1662500.0 | 810000.0 | 544320.0 |
| Switching | Non blocking Layer 1 capacity | 131752.3 | 3242160.4 | 390625.0 | 3325000.0 | 810000.0 | 1088640.0 |
| Routing | none (L3HW) | 130643.6 | 1586535.8 | 387536.3 | 1587348.6 | 810000.0 | 414720.0 |
Ethernet test results
| CRS812-8DS-2DQ-2DDQ-RM | AL52400 - all port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 2416.8 | 29349.6 | 6404.6 | 26233.2 | 9392.5 | 5109.5 |
| Bridging | 25 bridge filter rules | 1191.3 | 14467.1 | 1200.5 | 4917.2 | 1196.2 | 650.7 |
| Routing | none (fast path) | 2414.7 | 29324.1 | 6392.2 | 26182.5 | 9617.2 | 5231.8 |
| Routing | 25 simple queues | 1133.2 | 13761.6 | 1144.8 | 4689.1 | 1130.3 | 614.9 |
| Routing | 25 ip filter rules | 717.4 | 8712.1 | 711.1 | 2912.7 | 701.8 | 381.8 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
#5: Produktinformationen & Hilfe | Product informations & Help
| Benutzerhandbuch | User manual | Öffnen | Open |
| Softwarehandbuch [RouterOS] | Software manual [RouterOS] | Öffnen | Open |
| Blog [RouterOS, 60GHz, RMA, ...] | Blog [RouterOS, 60GHz, RMA, ...] | Öffnen | Open |
| Software/Updates [RouterOS, SwOS & CHR] | Software/Updates [RouterOS, SwOS & CHR] | Öffnen | Open |
| Kompatibilitätsliste [SFP/QSP] | Compatibility list [SFP/QSFP] | Öffnen | Open |
| Blockdiagramm | Block Diagram | Öffnen | Open |
| Sicherheits- und behördliche Informationen | Safety and regulatory information | Öffnen | Open |
| Konformitätserklärung (CE) | Declaration of conformity (CE) | Öffnen | Open |
