MikroTik RB750GL
Product.Nr.: RB/750GL
Manufacturer: MikroTik
71,34 EUR
incl. 19 % VAT
-
Zur Zeit nicht lagernd, bitte per E-Mail anfragen.
- delivery time nicht mehr lieferbar
- weight 0,3 kg
product description
#1: RB750GL
The RB750GL is a small SOHO router in a white plastic case. It has five independent Gigabit Ethernet ports and optional switch chip functionality for wire speed Gigabit throughput. It’s probably the most affordable MPLS capable Gigabit router on the market and now it is even more affordable than before. Compared to the previous model, the RB750GL has almost the same performance, but is significantly lower cost, only $59.95!
With it’s compact design and clean looks, it will fit perfectly into any SOHO environment.
#2: Included in delivery
- 1x RB750GL
- 1x 12V 1A power adapter
#3: Specifications - Technical details
| Details | |
|---|---|
| Product code | RB750GL |
| Architecture | MIPSBE |
| CPU | AR7242 |
| CPU core count | 1 |
| CPU nominal frequency | 400 MHz |
| Switch chip model | AR8327-BL1A |
| Dimensions | 113x89x28mm. Weight without packaging and cables: 129g |
| RouterOS license | 4 |
| Operating System | RouterOS |
| Size of RAM | 64 MB |
| Storage size | 64 MB |
| Storage type | NAND |
| MTBF | Approximately 100'000 hours at 25C |
| Tested ambient temperature | -30C to +70C |
Powering
| Details | |
|---|---|
| Number of DC inputs | 1 |
| Max power consumption without attachments | 5W |
| PoE in | Passive PoE |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 5 |
#4: Test results according to RFC2544
Ethernet test results
| RB750GL | AR7242 1G all port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 81.2 | 986.1 | 178.4 | 730.9 | 194.0 | 99.3 |
| Bridging | 25 bridge filter rules | 51.5 | 625.5 | 52.3 | 214.3 | 53.7 | 27.5 |
| Routing | none (fast path) | 81.2 | 986.1 | 167.0 | 684.0 | 183.7 | 94.1 |
| Routing | 25 simple queues | 81.2 | 986.1 | 88.5 | 362.4 | 92.8 | 47.5 |
| Routing | 25 ip filter rules | 37.6 | 457.0 | 38.4 | 157.1 | 37.5 | 19.2 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
#5: Product video & tips
- Product video: -
- Hints for starting and handling RouterOS in our Blog: RouterOS, Reset, Netinstall, Winbox, Wiki, Supout.rif, 60GHz Ausrichtung uvm
