MikroTik RouterBOARD RB711-5Hn

43,32 EUR

incl. 19 % USt
(Netto: 36,40 EUR)

zzgl. Versandkosten

Gewicht: 0,20 KG

Zur Zeit nicht lagernd. Bitte per Mail anfragen.

Zur Zeit nicht lagernd. Bitte per Mail anfragen.

Art.Nr.: RB711-5Hn

Produktbeschreibung

The RB711 is a small CPE type wireless router with an integrated 5GHz 802.11n 1x1 MIMO wireless card.

The integrated 5GHz 802.11a/n wireless card is capable of up to 22dBm transmit power output. It has built in 16kV ESD protection on the RF port.

This is a compact and easy to use solution for building your own CPE unit with a custom case and antenna

Supported frequency:
4800-6075Mhz

CPU:
Atheros AR7241 400MHz network processor

Memory:
DDR SDRAM onboard memory

Boot loader:
RouterBOOT

Data storage:
64MB onboard NAND memory chip

Ethernet:
1x 10/100 Mbit/s Fast Ethernet port with Auto-MDI/X

Wireless:
Built-in 5GHz AR9283 802.11a/n wireless card with 1x MMCX connector

miniPCI:
none

Extras:
Reset switch, Beeper

Serial port:
none

LEDs:
Power, NAND activity, 5 user LEDs

Power options:
Power over Ethernet: 8-30V DC on Ether1 (except power over dataline).

Dimensions:
10.5x10.5cm. Weight: 67g

Power consumption:
up to 4.5W at 18V full load (0.245A)

Operating System:
MikroTik RouterOS v4, Level3 license


RX sensivity:
802.11a: -92dBm @ 6Mbps to -76dBm @ 54Mbps
802.11n: -92dBm @ MCS0 to -73dBm @ MCS7 40MHz

TX power:
802.11a: 22dBm @ 6Mbps to 19dBm @ 54Mbps
802.11n: 22dBm @ MCS0 to 15dBm @ MCS7

Modulations:
OFDM: 64QAM, 16QAM, QPSK, BPSK
DSSS: CCK, DQPSK, DBPSK


Downloads

Datei Dateigröße
RB711A-5Hn-QuickGuide.pdf RB711A-5Hn-QuickGuide.pdf 0.47 MB
RB711-5Hn-Brochure.pdf RB711-5Hn-Brochure.pdf 1.19 MB
RB711-Dimensions.pdf RB711-Dimensions.pdf 1.63 MB
RB711G_5HnD-Dimensions.pdf RB711G_5HnD-Dimensions.pdf 0.07 MB
